HPC Maxi PRO

The HPC Maxi PRO fibre laser machines are engineered to offer full-sheet manufacturing capability with an optional protective enclosure for maximum operator safety. Open bed class 4 machines are also available, offering optimum access for loading and unloading operations.

Bed sizes of 2500 x 1300mm, 3000 x 1500mm and 4000 x 2000mm are available and all machines are supplied with a compatible water chiller unit, fan system for fume extraction and exhaust ducting. Self-contained fume filter options are available which means that external ventilation is not required, ideal for installations where access to an external wall or roof vent is not possible.

A Dual bed arrangement means that one bed can be inside the machine whilst the other is outside the machine. This allows simultaneous processing inside the machine and material handling outside the machine.

An automatic focus Raytools laser head, Yaskawa servo control and a state-of-the-art onboard Windows PC are cleverly engineered into each machine.

Because of the modular manner of construction, the Maxi PRO machine range is available with optional integrated tube cutting arrangement. This clever system makes use of an extended X axis and oversize gantry to provide plate cutting and tube cutting using a single machine chassis, laser source and head.

Quality and reliability throughout

The Maxi PRO range, with its 2500 x 1300mm, 3000 x 1500mm or 4000 x 2000mm working area, is manufactured for the most demanding applications and carefully engineered for maximum reliability.

The twin ball screws mated together with precision servo drive systems ensure maximum precision whilst our optional EN 60825 compliant enclosure and Allen Bradley Guardmaster safety switches ensure that operators are able to work safely with the machine at all times.

HPC Laser offer no obligation advice around the use of protective enclosures and selection of an appropriate laser source for your application. Care must be taken to match the target materials with a compatible laser source. With Max Photonics, Raycus, IPG and nLIGHT sources available we have a solution for every fibre laser cutting requirement.

Supplied complete and ready for work

Whether you are a small business looking to make your first steps into fibre metal cutting or a larger organisation considering a small fibre machine for optimising your production, the Maxi PRO fits the bill.

Our machines are delivered and installed by our own highly experienced engineers and are ready for work in record time upon arrival at site. We offer comprehensive onsite operator training once installation is complete, ensuring you’re self sufficient as quickly as possible. We then offer a comprehensive onsite warranty, onsite servicing, engineer callouts and spare parts in UK stock when you need us.

Making light work of a wide range of target materials, the Maxi PRO machines are sure to take your manufacturing capability to the next level.

Features:

• Laser sources include Max Photonics, Raycus, IPG and nLIGHT (contact us to discuss suitability)
• French Schneider electric components
• Japanese Yaskawa servo motors
• NSK – Excellent high precision long life bearings
• Hiwin square guide rails for heavy loads and longer working life

Performance:

• Working area – 2500 x 1300mm, 3000 x 1500mm and 4000 x 2000mm
• Laser powers available – 1000W / 1500W / 2000W / 3000W / 4000W / 6000W / 8000W / 10000W / 12000W
• Repeat position accuracy – ±0.02mm
• Max cutting thickness – up to 30mm mild steel, 30mm stainless steel, 25mm aluminium, 14mm brass and copper.  Please contact us to discuss your specific requirements.
• Max acceleration – 0.5G
• Max moving speed – 40m/min
