LSG200 Laser Marking Machine

An image of the Laserscript LSD200 Laser Marking Machine

Engraving coated steel with the LSG200

Model: LSG200 Laser Marking Machine

Price From: £4,995.00 (ex. VAT)

Laser Source: 60W CO2 Laser Tube

A conventional CO2 laser machine engraves material by making multiple passes across the work and moving forward following each pass.

The Laserscript LSG200 instead uses a clever “Galvo” head arrangement with no external moving parts. The laser beam is deflected from a series of dynamic mirrors in the head which provides an extremely fast process time, far in excess of a conventional CO2 machine.

Like a conventional CO2 engraving machine, the LSG200 laser engraver will engrave many non-metallic objects along with coated metals. In order to engrave uncoated metals, it is necessary to first apply a ceramic marking compound to the target component.

The engraving process is burned into the surface of the target component. Any surplus compound is then washed away, leaving an attractive and permanent marking.

Reliable, safe, permanent marking

The LSG200 is equipped with a 60W Co2 laser tube as standard. The engraving area is carefully assessed by application and the focus lens specified to provided maximum clarity across the entire engraving area.

With 100mm x 100mm engraving area as standard, we are also able to offer options of 200mm x 200mm and 300mm x 300mm.

The machines footprint is 1850(L) x 420(W) x 1230(H) mm.

The table height offers a 320mm Z axis adjustment to provide maximum flexibility of component size and shape. A customised safety-interlocked enclosure is also available to provide maximum operator safety in compliance with EN 60825.

If you are looking for increased processing speeds or the ability to mark onto bare metals, our LS110 fiber laser engraving machine has a fully integrated laser fibre source which will engrave onto uncoated metals without the use of a ceramic marking compound.

Rapid cutting of non-metallics

The Laserscript LSG200 is also capable of extremely high speed cutting of non-metallic objects

Within the maximum working areas mentioned above, the LSG is capable of cutting and engraving in a single operation, typically with sheet materials such as paper, card, plastics, rubbers, fabrics and leather.

Combine the LSG200 laser engraving machine with a CW4000 water chiller units and you have an extremely high-speed engraving and light cutting machine capable of incredible production rates 24/7.

Please Note

Item does not include delivery. A quote can be provided for delivery with installation and training by sending your address to sales@hpclaser.co.uk
